<3 grajhq 1 100% Germany /EU Origin

Conductix-Wampfler Vietnam - Conductix-Wampfler Viet Nam - Conductix-Wampfler-Vietnam

CAT/ NO: 081209-2X012

CURRENT COLLECTOR 0812 1P2PH 80A REV B

REV=REVERSE MODE GA=FASTENERS GALVANIZED

B=CONTACT FROM BELOW



1 100% EU Origin

TIVAL Sensors Vietnam

MODEL: FF142- 9 DAH

Art.code 1050002

Pressure switch with perbunan diaphragm

Adjustment range: 2...21 bar

Pressure connector: 3/8" female (polyamid)



1 100% Germany  Origin

Dold Vietnam

Art. No.:   0048701

Model: BN3081.63/61 AC50/60HZ 230V

EXTENSION MODULE



<3 janjsg 1 100% Germany  Origin

 LauterbachVietNam - Lauterbach Vietnam - Lauterbach-VietNam

Lauterbach VietNam - Lauterbach Debug Module VietNam - Lauterbach POWER DEBUG E50 VietNam

Model : Lauterbach LA-3504 - Debug Module
Thiết Bị kiểm tra, tìm lỗi và sửa lỗi trong chương trình điều khiển rồi nạp lên cho PLC - Debug Test Module

Lauterbach POWER DEBUG E50 Interface Signal Converter

c/w LA-1952 POWERSUPPLY-PP-US

c/w LA-1943 USB-3-CABLE

c/w LA-7411 TRIGGER-CONNECTOR

c/w LA-3544X ETHERNET-LICENSE



2 100% Germany Origin

Lauterbach-VietNam

Lauterbach VietNam - Lauterbach Debug Probe VietNam - Lauterbach DBG-TRICORE-PACK VietNam

Model : Lauterbach LA-3203 Debug Probe

Lauterbach DBG-TRICORE-PACK

c/w LA-3011 DCABLE-AUTO26-V3

c/w LA-7756A OCDS-TRICORE-A

c/w LA-1947 AUTO-FLAT10

c/w LA-1948 AUTO-FLAT20

c/w LA-1949 AUTO-FLAT26



3 100% Germany Origin

 Lauterbach Viet Nam

Lauterbach VietNam - Lauterbach LA-3849 VietNam - Lauterbach CON-AUTO26-JTAG16 VietNam

Model : Lauterbach LA-3849 Converter 26-pin Automotive Debug

Lauterbach CON-AUTO26-JTAG16



1 100% Korea Origin

Pora Vietnam

Model: PRC-5C5

Powder clutch

Successor of PRC-5C3 is PRC-5C5



<3 grajhq 1 100% EU Origin

Minimax Vietnam - Minimax Viet Nam - MinimaxVietnam - Minimax-Vietnam

P/N: 815392

Description:   Solenoid valve CO2-DN7-compl.



2 100% EU Origin

Minimax Vietnam

P/N: 131790

Description:   Gate valve AR DIN16271





<3 janjhq 1 100% Korea Origin

JPSYS VietNam - JPSYS Viet Nam - JPSYSVietNam - JPSYS VietNam - JPSYS-VietNam

Model: E-CORE [COIL]

E-CORE [COIL] 133mm



1 100% USA Origin

IMR Environmental Equipment, Inc. VietNam

Model: EX660-BASIC

IMR EX660-BASIC

Portable Multigas Detector

SMART Sensor Modules

-O2       0 - 30 %

-CO       0 -1,000ppm (or 2,000ppm)

-CH4     0 - 100% LEL

-H2S      0 - 100 ppm

-

-

included. (different configuration possible)

space for 2 additional sensor modules available  ( space for a total of  6 sensor modules)

gas information continuous and simultaneous on display

Main Functions and Features:

- SMART Sensor for easy change/exchange or add additional sensor modules without calibration needed.

- Intrinsically Safe design

- LCD Screen wide view

- High Alarm / low alarm for every   module  free customer adjustable

- Calibrating level adjustable, easy for calibrating

- Combustible gas channel with high - concentration protection function

- Low-voltage alert

- Data uploading to PC available

internal Memory  30,000 records

USB cable included

data transfer software included

- Audible, visual and vibration alarm method

-clip for  belt included

-calibration cover included

-charger  110-230 V  50/60 H� included

-sampling pump - optional

-gas sampling probe - optional

SMART sensor modules for a total of 20 different gases available



1 100% Germany Origin

EGE Elektronik Vietnam

ID No: S10831

Type SDN10831

Inline Flow sensors



 1 100% EU Origin

TIVAL Sensors Vietnam

MODEL: 1100031

TST 10.0, 16 bar, G1/4" BM, SW22, S763-4, 3+ 2-

Pressure Transmitter, stainless steel diaphragm

Operating voltage: 10 ... 32 V DC

Output signal: 4 ... 20 mA, 2-conductor Electrical connection: M12x1; 4-pin

PIN-assignment: 3=+, 2=-



1 100% Germany  Origin

Montwill Vietnam

Part no: M1-1SR4B.0001.K70BD

Description: Digital panelmeter 4-digit, unit: none

housing B96xH48xD38mm incl. plug in terminal

character height 14mm red

display of -1999 ... 9999 digits

min/max-value recording

programming interlock via access code

10 adjustable setpoints

protection class: IP65 at the front side

measuring input: current loop 4-20mA

connection: plug terminal

operation: at the front side over keyboard

including fastening with screw

manual M1_1SD / GB



<3 lucjhq 1 100% EU Origin

HIMMEL Vietnam - HIMMEL Viet Nam - HIMMELVietnam - HIMMEL-Vietnam

Code: 2140003677 -replace 2140000277

HIMMEL®-Flachmotor

KP75-MB/2-M12K HWG70 1:1 M16-LH / M12-RH

Getriebeposition Lage - Pos.11

*Motor und Getriebe in Schutzart IP64 (in Anlehnung an ATEX Klasse II 3D Ex tc IIIB T300°C Dc - IP64).

Norm / Drawing No.: 1NJ017709

K-Modellreihe / design series: K75

Typ / type: KP75-MB/2-M12K-WG

- - Lackierung / painting - -: -

Farbe / colour: RAL 7031 Blaugrau 2K / Blue grey 2K

- - Mechanische Daten / mechanical data - -: -

K-Maßblatt / dimension sheet: 1NJ017709

Bauform / mounting position: V5

K-Befestigungsseiten / mounting sides: einseitige Fußbearbeitung/one-sided foot machining

Lagerung-DE / Bearing-DE: DL (Doppellagerung / Double bearing)

Lagerung-NDE / Bearing-NDE: EL (Einfachlagerung / simple bearing)

Schutzart / protection class: IP64

- - Abtriebsvariante / Output variant - -: -

Abtriebs-Variante / Output variant: Flanschscheibe/Flange plate

W.Durchmesser / shaft diameter [mm]: 30

W. Länge / shaft length [mm]: 155 (Anfang Werkzeug bis Mitte Motor/ Tool contact

surface to motor axis)

Wellengewinde / shaft thread: M16-L.H. + M12-R.H.

K-Flanschscheiben Ø/ external diameter flange [mm]: 140

K-Werkzeugbreite / tool width [mm]: 2 - 5

- - - - - Elektrische Daten / electrical data - -: -

Kennzeichen/Zulassung|Identification/Certification: CE

Phasenanzahl / number of phases: 3~

Nennleistung / Nominalpower [kW]: 7.5

Betriebsart / Duty type: S6-60%

Polzahl / Poles: 2

Motordrehzahl nenn / Motor speed nom. [1/min; rpm]: 2890

Nennspannung / Nominalvoltage [V]: 400

Nennfrequenz / Nominal frequency [Hz]: 50

Nennstrom / Nominal current In [A]: 13.8

Schaltung / Wiring: S102 (D)

CosPhi / CosPhi: 0.9

Isolationsklasse / Insulation class: F

Wicklungsschutz / Motor protector: PTC 130°C

Versorgungsart / power supply: Netz-Betrieb / mains operation

Schaltbild Motor / Connection diagram motor: A0102100

Schaltbild Einbauten 1 / Con. diagram compon. 1: A01TP000

- - Elektr. Anschluss / electrical connection- -: -

K-elekt.Anschlussart/elec. connection mode: Klemmenkasten / Terminal Box

KK-Werkstoff / Terminal box material: Aluminium / aluminium

KK-Lage / Terminal box position: 2DK

KK-Verschraubung / gland: (2x)-M25x1,5 + (1x)-M16x1,5 + (3x)-M12x1,5

Außenerdung Motor / External grounding motor: Nicht vorhanden / not existing

- - Belüftung / Ventilation - -: -

Belüftungsart / Ventilation type: E - Eigenbelüftung/Self-ventilation

- - - - - Bremse / Brake - - - - - - - - - - - -: -

Bremstyp / Brake type: M12K [12Nm] (L8)

Bremssteuerspg / Brake supply voltage [V]: 360-440

Verschaltung / Connection: am Klemmbrett / on terminal block

Schaltbild Bremse 1 / Connection diagram brake 1: A01BA003

- - - - - Getriebe / Gearbox - - - - - - - - - -: -

K-Getriebetyp / K-Gear Type: Winkelgetriebe / angular gear [HWG70] (K75)

Getriebelage / Gear position: Pos11

Übersetzung / Ratio [i]: 1

Ölart / Oil type: CLP PAO 68 Synth.oil

Ölmenge / Oil quantity [l]: 0.27

- - - - Belastung, Kräfte / load, forces - - - -: -

Umgebungstemperatur / Ambient temperature /Ta [°C]: -20/+40

- - Leistungsschild / name plate - -: -

K-Leistungsschild / name plate: Klebeschild 90x60 /adhesive label 90x60

Leistungsschild Logo / name plate logo: HIMMEL

- - Warenverzeichnis / Harmonized codes - -: -

Zolltarifnummer / HS-Code: 85015220
