Ms ThảoCodes Giá Tốt - ListCodes#2-080426
<3 lucjhq 1 100% Germany Origin - jprob - - Systech FlowMeter for Gas Vietnam - Systech Flow Meter for Fluid Vietnam - Systech FlowMeter for Steam Vietnam - Systech Flow-Meter for Liquid Vietnam
Systech Flowmeter Vietnam - Systech Flow Meter Vietnam - Systech-Flow-Meter-Vietnam
Code: FL,CF,DN600,OHU,AAN,MC,SE,X100,PN40 Flow Sensor
deltaflow pitot tube DF25
TAG-no: DN600 line size - Flow Measurement for GAS, Steam
fluid FL - liquid
process connection CF - stud with DIN-flange acc. to DIN EN 1092-1 (flange pipe, gaskets,
screws are included in the delivery)
nominal diameter DN600 / 24''
exact inner diameter 590mm
exact wall thickness 10mm
pipe orientation OHU - horizontal pipe, installation from below (only liquid)
dp-connection AAN - welding ends (21,3 x 3.2mm)
mounting material MC - carbon steel (P235GH)
probe material SE - 1.4571 (SS316Ti) up to 550°C
insulation X100 - up to 100 mm
pressure range PN40
fluid unknown
operational pressure unknown
operational temperature unknown
process density unknown
flow rate unknown
fluid velocity unknown
differential pressure unknown
TAG-no. unknown
Note: in case of an order we need to know the missing information out of the
fieds mentioned with "unknown"
DF/Deltaflow: Systec Deltaflow product series.
FL/CF: Flow measurement for Gas, Steam, or Liquid (FL) with specific configuration (CF).
DN600: Nominal pipe diameter of 600mm.
AAN: Welding ends connection option.
PN40: Pressure rating (PN40 - 40 bar).
MC/SE/X100: Component/material specifications.
2 100% Germany Origin - Systech Flow Measurement for Gas Vietnam - Systech Flow Measurement for Fluid Vietnam - Systech Flow Measurement for Steam Vietnam - Systech Flow-Measurement for Liquid Vietnam
Systech Flow Measurement Vietnam - Systech FlowMeasurement Vietnam - Systech Flow-Measurement Vietnam
Code: FD,CF,DN200,OX,AAN,MC,SE,X100,PN40 Flowmeter
TAG-no: DN200 line size
deltaflow pitot tube DF25 - Flow Meter - Flowmeter based on Differential Pressure
fluid FD - steam
process connection CF - stud with DIN-flange acc. to DIN EN 1092-1 (flange pipe, gaskets,
screws are included in the delivery)
nominal diameter DN200 / 8''
exact inner diameter unknown
exact wall thickness unknown
pipe orientation OX - please specify
dp-connection AAN - welding ends (21,3 x 3.2mm)
mounting material MC - carbon steel (P235GH)
probe material SE - 1.4571 (SS316Ti) up to 550°C
insulation X100 - up to 100 mm
pressure range PN40
temp. transducer setting -
fluid unknown
operational pressure unknown
operational temperature unknown
process density unknown
flow rate unknown
fluid velocity unknown
differential pressure unknown
TAG-no. unknown
Note: in case of an order we need to know the missing information out of the
fieds mentioned with "unknown"
Code: FD,CF,DN200,OX,AAN,MC,SE,X100,PN40 Flowmeter based on Differential Pressure for measuring steam, gas and liquids
Tuychon
3 100% Germany Origin
Systech Viet Nam - Systech-Vietnam - SystechVietnam
Certificate of origin
1 100% EU Origin
OpenGear Vietnam
Model: OM1208-8E-GLB-LSP
OM1208-8E, 8 serial straight pinout,
8x 1GbE switch, 2x 1GbE with SFP, x86 1.4GHz 4-core
4GB mem 16GB SSD, TPM 2.0, dual power input, Global
Power Supply ,Lighthouse Service Portal Enabled
Chọn 1 trong 3
(bắt buộc)
2.1 100% EU Origin
OpenGear Vietnam
Model: OG-FNTS-OM1200-1YR
1-Year Foundation Support for OM1200
2.2 100% EU Origin
OpenGear Vietnam
Model: OG-FNTS-OM1200-3YR
3-Year Foundation Support for OM1200
2.3 100% EU Origin
OpenGear Vietnam
Model: OG-FNTS-OM1200-5YR
5-Year Foundation Support for OM1200
1 100% EU Origin
E+H Vietnam
Code: FDU91-RG2AA
Ultrasonic sensor
2 100% EU Origin
E+H Vietnam
Code: FMU90-R11CA111AA1A
Transmitter
1 100% Germany Origin
Baumuller Reparaturwerk Vietnam
Inverter Drive
SET-BM4446-SI2-21743-0308-1
as per Art.# 00426137
