1. Code: AV56A1KFX6YXGP50
Replaces part number AV56A1TFX1YXG007
THIN-LINE™ III Heavy Mill Duty Magnetic Modular Encoder 4.5"" C-Face Mount
Housing Type: 1 - Single Output
Rotor Bore Size: KF - 1 1/8"" Thru-Shaft Cam Screw Rotor for Wolong/GE Pitch Motor
Cover Style : X - No Cover Plate
Line Driver: 6 - 5-24v in, 5-24v out (7272) recommended for single-ended wiring (A,B,Z, no A/,B/,Z/)
Left Output PPR: Y - 1024 PPR
Right Output PPR: X - No Right Output, Single Output Only
Connector Options: G - Ind'l w/Northstar Pinout (EPIC Style connector), w/mating plug, LED diagnostics
Modifications: P50 - Special options for GE Motor, upgraded model including diagnostic LED & cam screw rotor and super magnetic shielding "
2. Code: AV6AS4B23QA2A000
AV6A Solid Shaft Optical Light Mill Duty Absolute Encoder
Communication Bus
S - SSI Communication
Flange
4 - 2.5 in. Square flange, 1.25 in. male pilot
Shaft Size
B - 3/8 inch x 5/8 inch long Solid Shaft, w/flat (flange #4 only)
Turns/bits/MT
2 - 4096 Turns/12 bits
CPR/bits Per Turn/ST
3 - 8192 Counts per Revolution/13 bits
Connector
Q - M23/12 pin w/o Plug, Kubler Pin Out
Connector Exit
A - Side/Radial exit
Output Coding
2 - Gray Coding
IP Rating
A - IP65 Shaft Seals
Modifications
000 - No Special Features "
3. Code: HS35MYX6CPU1CA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR: Y - 1024 PPR
Right Output PPR : X - No Right Output
Line Driver: 6 - 5-28v In/Out (7272)
Hollow Shaft Bore Size: C - 5/8 in. via insert
Connector Options: P - 10 Pin Mini-Epic Style with Plug
Mounting: U - Universal (Thru & End of Shaft)
Protection: 1 - Protective Basket Included Anti-Rotational Tether: C - 0.375 16 T-Bolt Fan Cover Tether
Channels and Modifications: A00 - Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ "
4. Code: HS35MYX6CPU1HA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR
Y - 1024 PPR
Right Output PPR
X - No Right Output
Line Driver
6 - 5-24v In/Out (7272)
Hollow Shaft Bore Size
C - 5/8 in. via insert
Connector Options
P - 10 Pin Mini-Epic Style with Plug
Mounting
U - Universal (Thru & End of Shaft)
Protection
1 - Protective Basket Included
Anti-Rotational Tether
H - A and F Tether Kits
Channels and Modifications
A00 - Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\
HS35MYX6CPU1HA00 Replaces part number HS35MYX6HPU1HA00 "
5. Code: HS35MYX6FCU0XA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder Left Output PPR
Y - 1024 PPR
Right Output PPR
X - No Right Output
Line Driver
6 - 5-24v In/Out (7272)
Hollow Shaft Bore Size
F - 1 in. (Native Bore)
Connector Options
C - 10 Pin MS Style with Plug, Avtron/BEI Phasing
Mounting
U - Universal (Thru & End of Shaft)
Protection
0 - No Protective Basket
Anti-Rotational Tether
X - No Tether Hardware
Channels and Modifications
A00 - Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ "
6. Code: HS35MYX6FCU1HA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR
Y - 1024 PPR
Right Output PPR
X - No Right Output
Line Driver
6 - 5-24v In/Out (7272)
Hollow Shaft Bore Size
F - 1 in. (Native Bore)
Connector Options
C - 10 Pin MS Style with Plug, Avtron/BEI Pin Out
Mounting
U - Universal (Thru & End of Shaft)
Protection
1 - Protective Basket Included
Anti-Rotational Tether
H - A and F Tether Kits
Channels and Modifications
A00 - Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\
HS35MYX6FCU1HA00 Replaces part number RA35MY6FCU1HA00 "
7. Code: HS35MYX8FPU1CA00
HS35M Hollow Shaft Magnetic Mill Duty Encoder
Left Output PPR : Y - 1024 PPR
Right Output PPR : X - No Right Output
Line Driver : 8 - 5-24v In/Out (HX)
Hollow Shaft Bore Size : F - 1 in. (Native Bore)
Connector Options : P - 10 Pin Mini-Epic Style with Plug
Mounting: U - Universal (Thru & End of Shaft)
Protection: 1 - Protective Basket Included Anti-Rotational Tether: C - 0.375 16 T-Bolt Fan Cover Tether
Channels and Modifications: A00 - Standard, No Special Features, All Channels A, A\, B, B\, Z, Z\ "
8. Code: M6-4S2HX51-W003
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 4 - 1 inch Hollow Shaft
Mounting : S - Standard End-of-Shaft Mounting
Line Driver : 8 - 5-24V In/Out Protected Line Driver
Left Output : H - High Res.
Right Output : X - No Right Output
Base PPR: 51 - 512 PPR
Marker : - - No Marker
Connector Options : W - Terminal with Cable Gland
Modifications: 003 - Includes B28390 Torque Arm Kit "
9. Code: M6C-4S1HX51-W003
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 4 - 1 inch Hollow Shaft
Mounting : S - Standard End-of-Shaft Mounting
Line Driver : 8 - 5-24V In/Out Protected Line Driver
Left Output : H - High Res.
Right Output : X - No Right Output
Base PPR: 51 - 512 PPR
Marker : - - No Marker
Connector Options : W - Terminal with Cable Gland
Modifications: 003 - Includes B28390 Torque Arm Kit
M6C-4S1HX51-W003 Replaces the obsolete M6-4S1HX51-W003 "
10. Code: M6C-4S8HX51-W003
DESCRIPTION: M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size: 4 - 1 inch Hollow Shaft
Mounting: S - Standard End-of-Shaft Mounting
Line Driver: 8 - 5-24V In/Out Protected Line Driver
Left Output: H - High Res
Right Output: X - No Right Output
Base PPR : 51 - 512 PPR
Marker: - - No Marker
Connector Options: W - Terminal with Cable Gland
Modifications: 003 - Includes B28390 Torque Arm Kit "
11. Code: M6C-5S8XH51-T003
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 5 - 1-1/8 inch Hollow Shaft
Mounting : S - Standard End-of-Shaft Mounting
Line Driver : 8 - 5-24V In/Out Protected Line Driver
Left Output : X - No Left Output
Right Output : H - High Res.
Base PPR : 51 - 512 PPR
Marker : - - No Marker
Connector Options: T - Terminal Block
Modifications : 003 - Includes B28390 Torque Arm Kit
**Replacement for the obsolete M6-5S3XH51-T003.....Please confirm before ordering…"
12. Code: M6C-5S8XH51-T005
M6C Flameproof Explosion Protected Encoder, ATEX/IECEx Zone 1
Hollow Shaft Bore Size : 5 - 1-1/8 inch Hollow Shaft
Mounting : S - Standard End-of-Shaft Mounting
Line Driver : 8 - 5-24V In/Out Protected Line Driver
Left Output : X - No Left Output
Right Output : H - High Res.
Base PPR : 51 - 512 PPR
Marker : - - No Marker
Connector Options: T - Terminal Block
Modifications : 005 - -40C Tested Unit with Torque Arm Kit Included "
